TL-SC3171G是一款3GPP無線網絡攝像機，為夜視型，內置紅外發光管，支持10米夜視，支持IEEE 802.11 b/g標準數據傳輸，配合監控軟件可同時管理最多16臺設備。以下文檔是TL-SC3171G用戶手冊，為英文版本，有需要的朋友可立即下載此文檔。
溫馨提示：
本文檔為PDF格式文檔，因此需確保在閱讀之前你已經安裝了pdf閱讀器，如果尚未安裝閱讀器，建議下載福昕pdf閱讀器或其他PDF閱讀器，進行安裝后閱讀。
TL-SC3171G用戶手冊目錄
Package Contents.........................................................................................................................1
Chapter 1 Minimum System Requirements.............................................................................2
Chapter 2 Physical Overview....................................................................................................3
2.1 Front View......................................................................................................................3
2.2 Bottom view....................................................................................................................3
Chapter 3 Using IP Camera via Web Browser.........................................................................5
3.1 Obtain the IP Address ....................................................................................................5
3.2 Windows Web Browser..................................................................................................7
3.3 Mac Web Browser..........................................................................................................9
Chapter 4 Using IP Camera via Mobile Phone ......................................................................12
4.1 3G Streaming Mobile View Mode.................................................................................12
4.2 3G Web Brower Mobile View Mode..............................................................................14
4.3 2.5G WAP Browser Snapshot Mode ............................................................................16
4.4 2.5G Web Browser Snapshot Mode.............................................................................16
4.5 Mobile View on Windows Mobile 6 Smart Phone.........................................................16
Chapter 5 Configuration of Main Menu..................................................................................20
5.1 Live View......................................................................................................................20
5.1.1 Snapshot..............................................................................................................20
5.1.1 Zoom in/out the image via the monitor window....................................................21
5.1.2 Video play buttons................................................................................................21
5.1.3 Audio buttons.......................................................................................................21
5.2 Setting..........................................................................................................................22
5.3 Client Setting................................................................................................................23
5.3.1 Mode....................................................................................................................23
5.3.2 View Size .............................................................................................................23
5.3.3 Protocol................................................................................................................24
5.3.4 Video Buffer .........................................................................................................24
5.4 Image Setup.................................................................................................................24
5.4.1 Brightness............................................................................................................24
5.4.2 Contrast ...............................................................................................................25
5.4.3 Saturation.............................................................................................................25
5.4.4 Hue ......................................................................................................................25
5.4.5 Default..................................................................................................................25
Chapter 6 Setting-BASIC.........................................................................................................26
6.1 System.........................................................................................................................26
6.1.1 Information...........................................................................................................26
6.1.2 Date/Time.............................................................................................................27
6.1.3 Initialize................................................................................................................28
6.2 Camera ........................................................................................................................29
6.2.1 General................................................................................................................29
6.2.2 MPEG4 ................................................................................................................30
6.2.3 MJPEG.................................................................................................................33
6.3 Network........................................................................................................................34
6.3.1 Information...........................................................................................................35
6.3.2 PPPoE (Point-to-Point Protocol over Ethernet)....................................................37
6.3.3 DDNS (Dynamic DNS).........................................................................................39
6.3.4 UPnP (Universal Plug and Play) ..........................................................................42
6.3.5 Bonjour.................................................................................................................43
6.3.6 IP Notification.......................................................................................................44
6.3.7 Wireless...............................................................................................................46
6.3.8 Messenger ...........................................................................................................49
6.4 Security........................................................................................................................54
6.4.1 Account................................................................................................................55
6.4.2 HTTPS.................................................................................................................56
Chapter 7 Setting-Advance.....................................................................................................58
7.1 FTP client.....................................................................................................................58
7.1.1 General................................................................................................................59
7.1.2 Alarm sending......................................................................................................59
7.1.3 Periodical sending................................................................................................62
7.2 SMTP...........................................................................................................................64
7.2.1 General................................................................................................................64
7.2.2 Alarm sending......................................................................................................67
7.2.3 Periodical sending................................................................................................70
7.3 HTTP event..................................................................................................................72
7.3.1 General................................................................................................................73
7.3.2 Alarm sending......................................................................................................73
7.4 Alarm output.................................................................................................................76
7.4.1 Setting..................................................................................................................77
7.5 Schedule......................................................................................................................79
7.5.1 Setting..................................................................................................................80
7.6 Alarm input...................................................................................................................81
7.6.1 Setting..................................................................................................................81
7.7 Motion detection...........................................................................................................82
7.7.1 Setting..................................................................................................................83
7.8 System Log..................................................................................................................83
7.8.1 Setting..................................................................................................................84
Appendix.....................................................................................................................................85
FAQ..............................................................................................................................................89
TL-SC3171G用戶手冊——后視圖
TL-SC3171G規格參數
接口
1個10/100M以太網RJ45口
1個直流插座
1個復位按鈕
1個3.5mm麥克風接口
1個3.5mm耳機接口
1個DI+/DI-/COM/NO接口
感應器
1/4” CMOS感應器
鏡頭
F2.0, 4.3mm
紅外燈
12個
夜視距離
10米
電源輸入
12V DC/1A
尺寸
136*75*47mm
使用環境
工作溫度: 0℃~40℃
存儲溫度: -40℃~70℃
工作濕度: 10%~90%RH 無凝結
存儲濕度: 5%~90%RH 無凝結
