Tebis是一款出自德國的數控自動化編程軟件，知道這款軟件的并不多，主要是在國內沒能很好的推廣。其實真正用起來還是蠻不錯的，因為它在歐洲還是蠻有地位的。現在Tebis軟件最新版本是4.0，免費分享給大家，歡迎下載！

Tebis 4.0 功能特色

Tebis has just the software you need: The industry packages and special packages are ideally configured for the model, mold and die, industrial design and mechanical engineering manufacturing sectors and for workstations with special tasks like laser cutting and trim machining. The packages are available for a variety of price/performance levels: Select an industry or special package and add to it to achieve precisely as what is needed.

Increasing machine productivity

Tebis helps you optimize the processes around your machinery. Reduce your costs, increase your manufacturing capacity and create more throughput. With multiple setup, multiple machine operation, etc.

Push-button solution for surfaces

Automatically detect irregularities in CAD surface models, repair them with a success rate of over 90% and reduce risk areas, surface patches and gaps at the click of a button ...

New for mechanical engineering

Whether for drive technology, motors and systems, hydraulics, pump housings or gearboxes – the new Tebis Mechanical Engineering industry packages provide the information you need ...

Your benefits from the Tebis Mold and Die industry packages:

No size limitations

Easy to learn and intuitive operation

Easily integrated in existing CAD environments with high-quality interfaces

Enables personnel to specialize in various areas such as design, manufacturing preparation and NC programming

High productivity with standardized and automated NC programming

Extensive machining options for surface, mesh and hybrid models

Broad application spectrum with comprehensive NC strategies for prismatic and 3D surface machining

High part surface quality with NC programs generated directly on CAD surfaces

Continuously improve your process quality with stored manufacturing knowledge in NC templates

Reliable processes with programming and simulation in a realistic manufacturing environment

Digital information flow throughout the process

Key features of the Tebis Mold and Die industry packages:

CAD functions for design

Comprehensive analysis functions for geometry

Repair and preparation functions for NC programming

Wide range of NC functions for 3D surface machining and for prismatic milling and drilling

Collision detection and avoidance

Full-width cut detection and avoidance

Extensive automation options

Manage real machines and tools in virtual libraries

Manage all machining steps in a central job manager

Quality checking right at the machine

Tebis4.0 優缺點說明

1 公認的tebis的速度很快。轉圖速度快，特別是與CATIA基本上無縫結合，轉大圖檔的話基本把cim和ug甩在后面。算刀路速度快，對大模二次開粗優勢明顯。

2 刀路安全，刀路算出來是實實在在的圖素，不像ug玩虛的。所以就算是2d刀路，就算圖檔是曲面，

（tebis里面沒實體）也可以檢測是否過切，強悍的要死，誤差不超過0.05。

3 tebis走橫向進給的時候可以走S型，讓刀路沒有突然變向，cim和ug沒見過，可能是我不會用，相對抬刀很安全。而且G00 不是在平面上，可以走斜線，真正的相對抬刀。

4 用等高來進行封閉槽的開粗的話，可以一直螺旋著下去，避免z向扎刀，cim三軸好像不太好辦吧，ug刀路不理想。

5 tebis自帶了十幾種控制器的后處理，夠用了。

6 tebis是個非參數話的軟件，所以如果你生成刀路后想更改參數小調整一下刀路的話，對不起，請重新作好了。但因為非參，所以你可以很方便的進行刀路旋轉，平移，鏡像，甚至你可以對模型進行修改，刪除，這在ug和cim中簡直不可想像，如果你編程坐標系變了，你甚至只要重新建個座標，后處理的時候選擇一下這個座標系就好了，

7 如果你的機床可以自動對零件進行測量校驗的話，tebis可以為檢測頭編制測量路徑。這個我也沒用過，只是看幫助玩了一下，唉，省了去三次元了。

8 開粗刀路實時生成毛胚，逼真的要死，比cim的那個remain stock要好很多。因為是實時生成毛胚體，所以不需要什么多軸毛胚功能了，自動實現。不過這個毛胚只能在開粗時用，精工刀路無法實現對毛胚更新，這點要比cim弱。

9 tebis的清角刀路夠漂亮，tebis可以在生成刀路之前就對刀路的范圍進行編輯。任何刀路都可以，cim應該辦不到，ug的清角可以作，但是與tebis有一定差距。

9 tebis對圖素的管理弱的一蹋糊涂，圖層的操作比cim和ug遜色不少。刀路的組織管理也僅僅靠層。一個刀路放在一個層里，讓人大跌眼鏡，要是還象ug和cim一樣作刀路的話，非死掉不行。2D刀路感覺特別特別的不方便，也有可能我還沒摸到門，設計功能幾乎可以忽略不計，測量功能也用著不爽。作小東西譬如鑲件，滑塊之類的會是很累的工作，沒法作模板，加工電極也是個麻煩事，nc中貌似沒有夾頭功能。所以說弱點也很明顯，不過以上言論有個前提，我用的是比較老的版本，新版本沒見過，應該上面問題都解決了吧。
